SaunaLife Model E6 — Ergo Series Outdoor Sauna Barrel Kit, Up to 3 Persons
Freight charge: $950 additional to the product price for delivery to the contiguous United States. Remote or complex delivery areas may not qualify for this flat rate and require an individual freight quote. Additional freight may apply if a heater system requires a separate pallet. Delivery is curbside by appointment. Confirm the applicable freight charge and delivery requirements before ordering.
SaunaLife Model E6 is ergo series outdoor sauna barrel kit, up to 3 persons. Review the specifications, included components and installation documents below to plan your installation.
Features
Model E6 Outdoor Sauna Barrel
- Thermo-Spruce material built for durability and low maintenance
- Spacious 6’5” interior height
- Engineered for simple DIY installation (1-day, 2-person)
- Industry-leading wall, bench, and backrest material thicknesses
- Superior thermal resistance (R-value)
- Contoured Thermo-Aspen bench for improved bather comfort
- Ergonomically arched backrest to support all body sizes
- Dual floor drains for effective water evacuation
- Black shingle roof kit for protection in any weather
- Roof drip edge rail for rainwater management
- Tempered bronze glass (5/16” thick)
- Enhanced bathing ambiance with lighting upgrades
- Heavy-duty stainless steel (AISI 430) barrel bands (1-7/8” wide x 1/8” thick)
- Paraffin oil is provided to enrich and preserve sauna barrel luster
- Extra Thermo-Spruce staves to ensure success
- Sauna heater guard
- Integrated ventilation
- Up to 3 bathers
- Exterior dimensions: 81"W (205.7 cm) x 59.1"D (150 cm) x 84.7"H (215 cm)
- Interior dimensions: 77.2"Diameter (196 cm) x 51"D (129.6 cm)
- Designed by SaunaLife and handcrafted in Northern Europe
Thermo-Spruce Advantages
- Superior durability
- Sustainable and environmentally friendly
- Low maintenance
- Weathers nicely
- Resists rotting and pests
- Warmer, more vibrant color
- Enhanced stability and strength
White LED Light System
- Dotless white glowing LED lighting
- Wi-Fi, app-based operation capability
- Wireless handheld remote (IP20) and control mounting cradle
- Water and heat-rated LED and wire connections (IP67)
- Flush or articulating mounting clips to set the ideal scene
- Low voltage (24-volt DC) operation for bathing safety
- 30’ light cable (IP67) to suit all installation applications
- Expandable to control up to four white LED light sources
Includes
Model E6 Outdoor Sauna Barrel
- Full-Length Staves
- Benches
- Backrest
- Glass Door
- Barrel Bands
- Roof Shingle Kit
- Cradles
- Fascia Boards
- Air Intake and Exhaust Vents
- Extra Staves (2)
- Fastener Kit
- Paraffin Oil, 16.9 oz (500 mL)
- Installation Manual
White LED Light System
- White LED Lights (2)
- Wi-Fi, App-Based Operation
- Wireless Handheld Remote and Mounting Cradle
- 90W Power Supply
- Driver
- 30’ Light Cable
- Mounting Clips and Screws
- Installation Manual
Specifications
| Model | MODEL E6 |
|---|---|
| Construction Material | Thermo-Spruce (Exterior) and Thermo-Aspen (Interior) |
| Exterior Dimensions | 81"W (205.7 cm) x 59.1"D (150 cm) x 84.7"H (215 cm) |
| Interior Dimensions | 77.2"Diameter (196 cm) x 51"D (129.6 cm) |
| Bench Dimensions | 51"W (129.6 cm) x 20.5"D (52 cm) |
| Door Dimensions | 23.2"W (59 cm) x 66.5"H (169 cm) |
| Product Weight | 1103 lbs (500.3 kg) |
| Shipping Dimensions | 80"W (203.2 cm) x 44"D (111.8 cm) x 34"H (86.4 cm) |
| Shipping Weight | 1202 lbs (545.2 kg) |
| Lighting | |
| Operating Voltage | 24VDC |
| Connection Type | IP67 Twist Lock 2 Pin |
| IP Rating | IP67 |
| Certification | cETLus, SGS, TUV |
| Power Supply | |
| Input Voltage | 120VAC |
| Output Voltage | 24VDC |
| Certification | UL, CE, FCC |
Manuals & Warranty
- SaunaLife Model E6 Sauna Barrel Installation Manual
- SaunaLife Sauna LED Light System Installation Manual
- SaunaLife Model E6 Sauna Barrel Dimensions
- SaunaLife Outdoor Sauna Care Guide
- SaunaLife Warranty Rev 260915
Warranty eligibility, exclusions and installation requirements are governed by the manufacturer documents linked above.
