HUUM CORE Black — CORE Series Sauna Heater, Black Exterior, Up to 10.5kW
by HUUM
SKU H1013072
Sold out
Original price
$2,081
-
Original price
$2,343
Original price
$2,081
$2,081
-
$2,343
Current price
$2,081
HUUM CORE Black — core series sauna heater, black exterior, up to 10.5kw. Review the specifications, included components and installation documents below to plan your installation.
Features
- 240V/1PH operation
- Sleek matte black metal casing
- Black steel inlay finish adds a cohesive look
- Can be completely embedded into a sauna bench
- Direct contact between stones and heating elements
- Stainless steel, industrial quality heating elements
- Designed, engineered, and made in Estonia
- Works with UKU Controls (sold separately)
- 66 pound stone capacity (required 2 boxes sold separately)
- Dimensions: 15.2"W (38.5 cm) x 15.2"D (38.5 cm) x 32.7"H (83 cm)
Includes
- Sauna Heater
- Adjustable Legs (4)
- Installation and Operation Manual
Specifications
| Model | CORE BLACK 6 |
|---|---|
| Room Size | 177-318 cu. ft. |
| Wattage Rating | 6500 |
| Amperage | 25 |
| Wire Size AWG | 10 |
| Model | CORE BLACK 9 |
|---|---|
| Room Size | 283-460 cu. ft. |
| Wattage Rating | 9000 |
| Amperage | 37.5 |
| Wire Size AWG | 8 |
| Model | CORE BLACK 11 |
|---|---|
| Room Size | 354-566 cu. ft. |
| Wattage Rating | 10500 |
| Amperage | 43.75 |
| Wire Size AWG | 8 |
| Model | CORE BLACK |
|---|---|
| Room Size | 177-566 cu. ft. |
| Wattage Rating | 6500-10500 |
| Voltage | 240 |
| Phase | 1 |
| Amperage | 25-43.75 |
| Circuit Breaker | See Installation and Operation Manual |
| Wire Size AWG | 10 or 8 |
| Safety Listing | CE (CE Certificate) |
| Minimum Ceiling Height | 80" (203 cm) |
| Safety Distance (Front to Back) | See Installation and Operation Manual |
| Safety Distance (Left to Right) | See Installation and Operation Manual |
| Stone Capacity | 66 lbs (30 kg) |
| Stone Size | 2" to 4" (5-10 cm) |
| Width | 15.2" (38.5 cm) |
| Depth | 15.2" (38.5 cm) |
| Height | 32.7" (83 cm) |
| Weight | 41.9 lbs (19 kg) |
| Shipping Weight with Sauna Stones | 107.9 lbs (48.9 kg) |
Manuals & Warranty
- HUUM CORE Sauna Heater IOM
- HUUM Element Requirements
- HUUM Stone Requirements
- Sizing Your HUUM
- HUUM_Warranty_terms_v4_ENG
Warranty eligibility, exclusions and installation requirements are governed by the manufacturer documents linked above.
HUUM warranty terms contain exclusions for accessories, heating elements, stones, stove glass and ash grates, and controller sensors. See the current terms above; no blanket coverage is implied.
